01. Hiiaka Data
Designation MPC: Haumea 1 Hiiaka
Alternate Names: (136108) 2003 El61 1, S/2005 (2003 EL61) 1
Diameter approx. - 350 km
Mean Radius - ~155 km
Density (gm/cm3) -
Distance from - (km) -
Period of rotation (days)  -
Semi-major axis - 49.880
±198 km
Eccentricity - 0.0513
±0.0078
Period of orbit around  49.12
±0.03 (days)
Orbital velocity (km/sec) -
Eccentricity of orbit -
Resonance - Close to 8:3
Inclination of orbit - 126.356
±0.064°
Mean Density - (unknown; close to 1 if water ice)
Mass - 1.79
±0.11 x10x19 (0.45% of Haumea)
Temperature - 32
±3 K
Escape velocity (km/sec) -
Visual albedo -
Apparent magnitude  - 3.3 difference from primary's 17.3
Discovered: 26.01. 2005 Mike Brown , Chad Trujillo, David Rabinowitz, et al
Keck Telescope and the Hubble Space Telescope
Hiiaka
Namaka
Hauma
Thebe
01. Charon Moon Data
Mass (kg) 1.90e+21
Radius (km) 586
Density (gm/cm3) 1.83
Distance from Pluto (km) 19,640
Period of rotation (days) 6.38725
Period of orbit (days) 6.38725
Orbital velocity (km/sec) 0.23
Eccentricity of orbit 0.00
Inclination of orbit (°) 98.80
Escape velocity (km/sec) 0.610
Visual albedo 0.5
Visual magnitude  16.8
Discovered: 1978 J.Cristy
Thebe
Thebe
Haumea - Hi'iaka
Thebe
Moons
Main Index
Space Cosmology
Science Research
*
About
Science Research
Science Theories
Desk
Site Map
BookShelf
Short-Cut
PLANETS
SOLAR SYSTEM
DWARF PLANETS
SOLAR SYSTEM
MOONS OR SATELITES
Moons Within Our Solar System
Haumea
Makemake
Eris
Pluto
Neptune
Uranus
Saturn
Jupiter
Arstroid belt
Mars
Earth
Mercury
Venus
The Sun
The Hills
Cloud
The Oort
Cloud
Ceres
Designed by Nigel G Wilcox
Powered By AM3L1A
Copyright ©  by Nigel G Wilcox  ·  All Rights reserved  ·  E-Mail: ngwilcox100@gmail.com

Menu
Luna - Moon
Sedna
Kuiper belt
Varuna
Quaoar
Sat menu
Pages within this section:
Pages:

1
2
3
4
Further Data
Hiʻiaka was the first satellite discovered around Haumea. It was discovered on 26 January 2005 and nicknamed "Rudolph" by the discovery team before being assigned an official name.
Its measured brightness is 5.9±0.5%, translating into a diameter of about 22% of its primary, or in the range of 320 km, assuming similar infrared albedo. To put this in perspective, if Hi'iaka were in the asteroid belt, it would be larger than all but the four largest asteroids, after 1 Ceres, 2 Pallas, 4 Vesta, and 10 Hygiea. In spite of its relatively large size, however, lightcurve studies suggest that Hi'iaka is not a gravitationally collapsed spheroid; they further suggest that Hi'iaka is not tidally locked and has a rotation period of about 9.8 hours.

Mass
The mass of Hiʻiaka is estimated to be (1.79±0.11)×1019 kg using precise relative astrometry from Hubble Telescope and Keck Telescope and applying 3-body, point-mass model to the Haumean system.

Spectrum and composition
The near infrared spectrum of Hiʻiaka is dominated by water-ice absorption bands, which means that its surface is made mainly of water ice. The presence of the band centered at 1.65 μm indicates that the surface water ice is primarily in the crystalline form. Currently it is unclear why water ice on the surface has not turned into amorphous form as would be expected due to its constant irradiation by cosmic rays
Two small satellites were discovered around Haumea (which was at that time still designated 2003 EL61) through observations using the W.M. Keck Observatory by a Caltech team in 2005. The outer and larger of the two satellites was discovered 26 January 2005, and formally designated S/2005 (2003 EL61) 1, though nicknamed "Rudolph" by the Caltech team.The smaller, inner satellite of Haumea was discovered on 30 June 2005, formally termed S/2005 (2003 EL61) 2, and nicknamed "Blitzen". On 7 September 2006, both satellites were numbered and admitted into the official minor planet catalogue as (136108) 2003 EL61 I and II, respectively.

The permanent names of these moons were announced, together with that of 2003 EL61, by the International Astronomical Union on 17 September 2008: (136108) Haumea I Hiʻiaka and (136108) Haumea II Namaka. Each moon was named after a daughter of Haumea, the Hawaiian goddess of fertility and childbirth. Hiʻiaka is the goddess of dance and patroness of the Big Island of Hawaii, where the Mauna Kea Observatory is located. Nāmaka is the goddess of water and the sea; she cooled her sister Pele's lava as it flowed into the sea, turning it into new land.

In her legend, Haumea's many children came from different parts of her body. The dwarf planet Haumea appears to be almost entirely made of rock, with only a superficial layer of ice; most of the original icy mantle is thought to have been blasted off by the impact that spun Haumea into its current high speed of rotation, where the material formed into the small Kuiper belt objects in Haumea's collisional family. There could therefore be additional outer moons, smaller than Namaka, that have not yet been detected. However, HST observations have confirmed that no other moons brighter than 0.25% of the brightness of Haumea exist within the closest tenth of the distance (0.1% of the volume) where they could be held by Haumea's gravitational influence (its Hill sphere). This makes it unlikely that any more exist.

Surface properties
Keck telescope image of Haumea (center), Hiʻiaka (above), and Namaka (below).
Hiʻiaka is the outer and, at roughly 310 km in diameter, the larger and brighter of the two moons. Strong absorption features observed at 1.5, 1.65 and 2 µm in its infrared spectrum are consistent with nearly pure crystalline water ice covering much of its surface. The unusual spectrum, and its similarity to absorption lines in the spectrum of Haumea, led Brown and colleagues to conclude that it was unlikely that the system of moons was formed by the gravitational capture of passing Kuiper belt objects into orbit around the dwarf planet: instead, the Haumean moons must be fragments of Haumea itself.

The sizes of both moons are calculated with the assumption that they have the same infrared albedo as Haumea, which is reasonable as their spectra show them to have the same surface composition. Haumea's albedo has been measured by the Spitzer Space Telescope: from ground-based telescopes, the moons are too small and close to Haumea to be seen independently. Based on this common albedo, the inner moon, Namaka, which is a tenth the mass of Hi?iaka, would be about 170 km in diameter.

The Hubble Space Telescope (HST) has adequate angular resolution to separate the light from the moons from that of Haumea. Photometry of the Haumea triple system with HST's NICMOS camera has confirmed that the spectral line at 1.6 µm that indicates the presence of water ice is at least as strong in the moons' spectra as in Haumea's spectrum.

The moons of Haumea are too faint to detect with telescopes smaller than about 2 metres in aperture, though Haumea itself has a visual magnitude of 17.5, making it the third-brightest object in the Kuiper belt after Pluto and Makemake, and easily observable with a large amateur telescope.

Orbital characteristics
A view of the orbits of Hiʻiaka (blue) and Namaka (green)

Illustration of mutual events between Haumea and Namaka during 2009–2011
Hiʻiaka orbits Haumea nearly circularly every 49 days. Namaka orbits Haumea in 18 days in a moderately elliptical, non-Keplerian orbit, and as of 2008 was inclined 13° with respect to Hiʻiaka, which perturbs its orbit. Because the impact that created the moons of Haumea is thought to have occurred in the early history of the Solar System, over the following billions of years it should have been tidally damped into a more circular orbit. Namaka's orbit has likely been disturbed by orbital resonances with the more-massive Hiʻiaka due to converging orbits as they moved outward from Haumea due to tidal dissipation. They may have been caught in and then escaped from orbital resonance several times; they currently are in or at least close to an 8:3 resonance. This resonance strongly perturbs Namaka's orbit, which has a current precession of its argument of periapsis by about
6.5° per year, a precession period of 55 years.

At present, the orbits of the Haumean moons appear almost exactly edge-on from Earth, with Namaka having periodically occulted Haumea from 2009 to 2011. Observation of such transits would provide precise information on the size and shape of Haumea and its moons, as happened in the late 1980s with Pluto and Charon. The tiny change in brightness of the system during these occultations required at least a medium-aperture professional telescope for detection. Hiʻiaka last occulted Haumea in 1999, a few years before its discovery, and will not do so again for some 130 years. However, in a situation unique among regular satellites, the great torquing of Namaka's orbit by Hiʻiaka preserved the viewing angle of Namaka–Haumea transits for several more years.
